1/7.5" Color 2‑Megapixel (1500 x 1500) CameraCubeChip® with PureCel®Plus-S Technology
  • SKU
    OCH2B30-RAUA-001A
  • Package
    CameraCubeChip®

Smallest Camera Module for 3D Intraoral Dental Scanners

The new OCH2B30 camera module for three-dimensional (3D) intraoral dental scanners features a compact CameraCubeChip® package in an ultra-small form factor (2.6 mm x 2.6 mm), which is especially important when there are multiple cameras in each scanning device. It offers exceedingly high image quality and MIPI interface for cameras in benchtop, standalone and portable intraoral scanners.

The OCH2B30 camera module has a 2‑megapixel (MP) resolution square-format CMOS image sensor with a 1.12‑micron (µm) pixel built on OMNIVISION’s latest PureCel®Plus‑S stacked-die technology, which enables its ultra-small size. At 1500 x 1500 resolution, the OCH2B30 achieves 60 frames per second (fps), and at 720p resolution, 120 fps.

The OCH2B30 is tested for EMC/EMI compliance and sterilization, and it is biocompatible and waterproof. Because it passes OMNIVISION’s rigorous production testing, it is guaranteed to be within the stated electrical, mechanical and optimal specifications, and hence does not require tuning or calibration.

June 17, 2024: OMNIVISION Announces Smallest Camera Module for 3D Intraoral Dental Scanners

Automatic black level calibration (ABLC)

Programmable controls for:
– Frame rate
– Mirror and flip
– Binning
– Cropping
– Windowing

Support for dynamic DPC

Supports output formats: 10-bit RGB non-HDR

Supports horizontal and vertical subsampling

Standard serial SCCB interface

Supports typical images sizes:
– 1500 x 1500
– 960 x 540
– 1280 x 720
– 640 x 480

2-lane MIPI TX interface with speeds up to 1.0 Gbps/lane

HDR support: Stagger HDR 2 exposure timing

Two on-chip phase lock loops (PLLs)

Built-in temperature sensor

Non-autoclavable

1.116 μm x 1.116 μm pixel

  • Spec
    OCH2B30
  • Analog / Digital
    Digital
  • Category
    1500 x 1500
  • CFA (Chroma)
    Color
  • Frame Rate
    Full @ 60 fps
  • Image Area
    1691.856 x 1691.856 μm
  • Interface
    MIPI
  • Optical Format
    1/7.5"
  • Output Format
    10-bit RGB RAW
  • Package
    Black Coating
  • Pixel Size
    1.116 µm
  • Power Requirement
    Active: 124 mW (1500 x 1500 @ 60 fps), Standby: 2 mA
  • Resolution
    1500 x 1500
  • Shutter Type
    Rolling Shutter
  • Technology
    PureCel®Plus-S
  • Use Case
    Dental Mirror, Intra Oral Scanner
  • Operating Temperature
    -20°C to +70°C
  • Package Dimensions
    2565 x 2565 x 3634 μm
  • Category
    2MP to 5MP
