Medical RGB-IR Image Sensor Reduces Endoscope Size, Cost, Power and Heat by Half
1/6" RGB‑IR 1080p (1920 x 1080) HD CMOS Image Sensor with PureCel® Technology
  • SKU
    OH02A1S-GA5A
  • Package
    COB, RW

Medical RGB-IR Image Sensor Reduces Endoscope Size, Cost, Power and Heat by Half

OMNIVISION’s OH02A1S is the world’s first RGB‑IR medical image sensor, providing simultaneous white-light RGB captures and infrared monochrome captures in a single CMOS sensor for cancer diagnosis and treatment. While endoscopic precancer and cancer detection procedures are performed using IR light, surgeons also need RGB light to confirm any abnormalities detected using infrared. Previously, this could only be accomplished by integrating two independent imager sensors, which resulted in endoscopes with a larger size, higher cost and higher power consumption, thereby excessively heating the tip of the endoscope.

Built on OMNIVISION’s PureCel® pixel architecture, the OH02A1S offers 4×4 binning for the highest image quality, high quantum efficiency for excellent low-light performance, and a high dynamic range for clarity in scenes with widely contrasting bright and dark areas. The sensor can provide 1080p (1920 x 1080) resolution at 60 frames per second (fps) or 720p (1280 x 720) at 90 fps, via a 2‑lane MIPI serial output. The OH02A1S also integrates 2 kilobits of one-time programmable memory on-chip. It consumes just 90 milliwatts at full power, generating less heat for greater patient comfort.

With the OH02A1S, both IR and RGB images can now be captured using a single chip, allowing the surgeon to switch between high quality RGB and IR in real time, or to display both images simultaneously on one (overlay) or two (side-by-side) monitors. Additionally, the smaller size and reduced heat allow the endoscope to reach much farther into the body than was previously possible with larger-outer-diameter, two-imager designs. Alternatively, designers can use the extra space to add more or larger illumination (fiber or LED), or a larger working channel for endoscopic tools.

The OH02A1S image sensor is available today in an RW package and the chip-scale package will be available based on project demand.

September 29, 2020: OMNIVISION Introduces World’s First Medical RGB-IR Image Sensor; Reduces Endoscope Size, Cost, Power and Heat by Half

1.4 µm x 1.4 µm pixel

Optical size of 1/6″

Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports output formats:
– 10-bit RAW RGB-IR

Supports images sizes:
– 1080p (1920 x 1080)
– 720p (1280 x 720)

Standard serial SCCB interface

Up to 2-lane MIPI serial output interface (supports maximum speed up to 1000 Mbps/lane)

Embedded 2 kilobits of one-time programmable (OTP) memory for customer use

Programmable I/O drive capability

Light sensing mode (LSM)

RGB-IR in a 4×4 pattern

  • Spec
    OH02A1S
  • Analog / Digital
    Digital
  • Category
    2MP to 5MP
  • CFA (Chroma)
    RGB-Ir
  • Frame Rate
    Full @ 60 fps
  • Image Area
    2728.8 x 1549.8 µm
  • Interface
    MIPI, SCCB
  • Optical Format
    1/6"
  • Output Format
    10-bit RAW RGB-Ir
  • Package
    RW
  • Package Dimensions
    3875 x 2939 µm
  • Pixel Size
    1.4 µm
  • Resolution
    1080p
  • Shutter Type
    Rolling Shutter
  • Technology
    PureCel®
  • Use Case
    Stomach and Intestine - Colonoscope, Stomach and Intestine - Gastroscope, Stomach and Intestine - Laparoscope
  • Operating Temperature
    -30°C to +85°C
