SKUOH08B10-A92A-001A-Z
-
PackageCSP
Industry’s First 8-Megapixel Medical-Grade Image Sensor with Nyxel® Technology for Single-Use and Reusable Endoscopes
OMNIVISION’s next-generation OH08B CMOS image sensor is the first 8‑megapixel (MP) resolution sensor for single-use and reusable endoscopes, along with the OH08A. Targeted at endoscopes with a 10‑12 mm outer diameter, such as gastroscopes, duodenoscopes, amnioscopes, laparoscopes and colonoscopes, the OH08B delivers high image quality, up to 4K2K resolution at 60 fps, greatly improving the doctor’s ability to visualize the human anatomy during these important procedures. Additionally, the OH08B is the first medical-grade image sensor to use OMNIVISION’s award-winning Nyxel® Near-Infrared (NIR) Technology–bringing revolutionary imaging capabilities beyond the visible spectrum to the medical industry. The sensor offers better performance in color and IR sensitivity, enabling doctors to see sharper video during NIR, fluorescence, chromo-endoscopy and virtual endoscopy procedures. Also, higher sensitivity results in less illumination, thus reducing the heat at the tip of the endoscope.
The OH08B has a 1/1.8‑inch optical format and uses a larger 2.0 µm PureCel® pixel in a 8.9 mm x 6.3 mm package. The sensor features OMNIVISION’s Nyxel® Technology, providing 3x quantum efficiency (QE) improvement at both the 850 nm and 940 nm NIR wavelengths. The excellent QE also allows the use of lower-power IR illumination, resulting in significantly reduced chip-on-tip power consumption.
Other key features of the OH08B include a 11‑degree chief ray angle, enabling the use of lenses with large field of view and short focus distance, pulse width modulation output LED drivers, and 4‑lane MIPI output with raw data. This sensor is stereo ready with frame synchronization to support a host of depth perception applications. Plus it’s autoclavable for reusable endoscope sterilization.
2 μm x 2 μm pixel
Optical size of 1/1.8″
QE enhancement in 850 nm and 940 nm
Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing
Supports output formats: 12-/10-bit RAW RGB
Supports images sizes:
– 4K (3840×2160)
– 2560 x 1440
– 1080p (1920×1080)
– 720p (1280×720)
Supports 2×2 binning
Standard serial SCCB interface
12-bit ADC
Up to 4-lane MIPI/LVDS serial output interface (supports maximum speed up to 1500 Mbps/lane)
2-exposure staggered HDR support
Programmable I/O drive capability
Light sensing mode (LSM)
PLL with SSC support
Support for FSIN
-
SpecOH08B
-
Analog / DigitalDigital
-
Category8MP to 13MP
-
CFA (Chroma)Color
-
Frame RateFull @ 60 fps
-
Image Area7736.256 x 4379.616 µm
-
InterfaceMIPI / LVDS
-
Optical Format1/1.8"
-
Output FormatRAW
-
PackageCSP
-
Package Dimensions8939.2 x 6340 μm
-
Pixel Size2.0 µm
-
Power RequirementActive: 240 mA, XSHUTDOWN: <10 µA
-
Resolution8MP
-
Shutter TypeRolling Shutter
-
TechnologyNyxel®, PureCel®
-
Use CaseStomach and Intestine - Colonoscope, Stomach and Intestine - Gastroscope, Stomach and Intestine - Laparoscope
