OS03B10 Security Camera
1/2.7" Color 3‑Megapixel (2304 x 1296) CMOS Image Sensor with OmniPixel®3‑HS Technology
  • SKU
    OS03B10-A41A-001A
  • Package
    CSP

3‑Megapixel Image Sensor with OmniPixel®3‑HS Brings the Most Vivid Pictures to Security, IP and HD Cameras

OMNIVISION’s OS03B10 CMOS image sensor brings high-quality digital images and high-definition (HD) video to security surveillance, IP and HD analog cameras in a 3‑megapixel (MP) 1/2.7‑inch optical format (OF). The OS03B10 image sensor features a 2.5 µm pixel that is based on OMNIVISION’s OmniPixel®3‑HS technology. The high-performance, cost-effective solution uses high-sensitivity frontside illumination (FSI) to detect objects better than the human eye for true-to-life color reproduction in bright and dark conditions.

The OS03B10 is pin2pin compatible with the 2MP 1/2.9‑inch OF OS02G10, allowing customers to seamlessly upgrade to a 3MP image sensor, greatly improving the image capture and HD video of their security products without having to redesign them.

By introducing an advanced 2.5 µm pixel architecture, the OS03B10 achieves excellent low-light sensitivity, signal-to-noise ratio, full-well capacity, quantum efficiency and low-power consumption. It has a 16:9 video format at 30 frames per second. Default and programmable modes allow for a more convenient way of controlling the parameters of frame size, exposure time, gain value, etc. It also offers image control functions such as mirror and flip, windowing, auto black level calibration, defective pixel correction, black sun cancellation and more. The OS03B10 supports DVP and MIPI interfaces.

March 30, 2022: OMNIVISION’s New 3‑Megapixel Image Sensor with OmniPixel®3‑HS Brings the Most Vivid Pictures to Security, IP and HD Cameras

Programmable controls:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports 2×2 color binning function

Supports output formats: 10-bit/12-bit RAW RGB

SCCB control interface for register programming

Supports MIPI 2-lane serial output interface

Supports DVP 12-bit output interface

Supports image sizes: 2312 x 1304 @ 30 fps

Supports automatic black level calibration

Supports multi-camera synchronous function

  • Spec
    OS03B10
  • Analog / Digital
    Digital
  • Category
    2MP to 5MP
  • CFA (Chroma)
    Color
  • Frame Rate
    2312 x 1304 (10-bit): 30 fps, 2312 x 1304 (12-bit): 15 fps
  • Image Area
    5780 x 3260 μm
  • Interface
    DVP, MIPI
  • Optical Format
    1/2.7"
  • Output Format
    10-bit/12-bit RAW RGB
  • Package
    CSP
  • Pixel Size
    2.5 µm
  • Power Requirement
    Active: 135 mW, XSHUTDOWN: 15 µA
  • Resolution
    3MP
  • Shutter Type
    Rolling Shutter
  • Technology
    OmniPixel®3‑HS
  • Use Case
    Commercial / Industrial Security Cameras - Fixed box camera, Commercial / Industrial Security Cameras - Fixed bullet camera, Commercial / Industrial Security Cameras - Fixed dome camera, Commercial / Industrial Security Cameras - Modular camera, Commercial / Industrial Security Cameras - Panorama camera, Commercial / Industrial Security Cameras - PTZ camera, Smart Home Monitoring - Indoor security camera, Smart Home Monitoring - Indoor webcam, Smart Home Monitoring - Smart doorbell
  • Operating Temperature
    -30°C to +85°C
