OS04C10 1/3" color CMOS 4 megapixel (2688 x 1520) image sensor with PureCel®Plus and Nyxel® technologies
1/3" Color 4‑Megapixel (2688 x 1520) CMOS Image Sensor with PureCel®Plus and Nyxel® Technologies
  • SKU
    OS04C10
  • Package
    CSP

4MP, 2‑Micron Image Sensor for IoT and Home Security Cameras with PureCel®Plus and Nyxel® NIR Ultra Low Light Technologies

OMNIVISION’s OS04C10 is a 2.0‑micron pixel, 4 megapixel (MP) resolution image sensor for both IoT and home security cameras. When paired with the designer’s selected platform, the OS04C10 can enable a system ultra low power mode for battery-powered cameras with AI functionality. Additionally, it provides high 2688 x 1520 resolution with a 16:9 aspect ratio, while adding the premium near-infrared (NIR) and ultra low light, SNR1 performance of its Nyxel® and PureCel®Plus technologies. This sensor also offers multiple high dynamic range (HDR) options for the highest quality 4MP still and video captures of fast-moving objects at 60 frames per second.

The OS04C10 is built on the PureCel®Plus pixel architecture to achieve a superior low-noise design, providing an SNR1 that is 150% better than OMNIVISION’s prior-generation OV4689 4MP mainstream security sensor. This new sensor maintains the same high 4MP resolution as the popular OV4689, while adding improved NIR, ultra low light and HDR performance for these IoT and home security cameras, along with a new ultra low power mode that consumes 98.9% less power than the normal mode for longer battery life.

OMNIVISION’s industry-leading NIR Nyxel® technology, combined with its PureCel®Plus technology and multiple HDR options, enables the OS04C10 to work equally well in all lighting conditions. It can detect incident light in both the visible and NIR wavelengths, while producing precise color and monochrome images for security applications.

The OS04C10 is infused with Nyxel® technology, which provides exceptional quantum efficiency (QE), enabling the sensor to see better and farther at both the 850 nm and 940 nm NIR wavelengths. Such excellent QE also enables the use of lower power IR illumination in total darkness, resulting in significantly reduced system-level power consumption. Additionally, 940 nm NIR lighting cannot be detected by the human eye in dark indoor settings, while 850 nm light is ideal for outdoor security cameras. The OS04C10’s ability to capture crisp, clear images using undetectable 940 nm NIR light means that indoor security cameras will not disturb sleeping residents and can be easily concealed from unwanted prowlers.

January 6, 2021: OMNIVISION Announces Best in Class 4MP, 2 Micron Image Sensor for IoT Security Cameras With Nyxel® NIR and PureCel®Plus Ultra Low Light Technologies

Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports output formats:
– 12-bit/10-bit RAW RGB

Supports images sizes:
– Full (2688×1520)
– 1080p (1920×1080)
– 720p (1280×720)
– AO_720p (1280×720)
– AO_360p (640×360)

Supports 2×2 binning

Standard serial SCCB interface

Up to 4-lane MIPI serial output interface (supports maximum speed up to 1500 Mbps/lane)

Add staggered HDR RAW data output

Programmable I/O drive capability

Built-in temperature sensor

MIPI serial output interface (1-lane, 2-lane, or 4-lane)

Image quality controls:
– Defect pixel correction
– Automatic black level calibration

  • Spec
    OS04C10
  • Analog / Digital
    Digital
  • Category
    2MP to 5MP
  • CFA (Chroma)
    Color
  • Frame Rate
    Full @ 60 fps
  • Image Area
    5402.592 x 3068.928 μm
  • Interface
    MIPI
  • Optical Format
    1/3"
  • Output Format
    RAW
  • Package
    CSP
  • Pixel Size
    1.998 μm
  • Power Requirement
    Active: 155 mW, XSHUTDOWN: <10 µA
  • Resolution
    4MP
  • Shutter Type
    Rolling Shutter
  • Technology
    HDR, Nyxel®, PureCel®Plus
  • Use Case
    Commercial / Industrial Security Cameras - Fixed box camera, Commercial / Industrial Security Cameras - Fixed bullet camera, Commercial / Industrial Security Cameras - Fixed dome camera, Commercial / Industrial Security Cameras - Modular camera, Commercial / Industrial Security Cameras - Panorama camera, Commercial / Industrial Security Cameras - PTZ camera, Smart Home Monitoring - Indoor security camera, Smart Home Monitoring - Indoor webcam, Smart Home Monitoring - Smart doorbell
  • Operating Temperature
    -30°C to +85°C
