16:10 Aspect Ratio, 5.2MP Resolution Image Sensor Designed for Laptops and IoT Devices
1/4.7" Color 5.2‑Megapixel (2888 x 1808) CMOS Image Sensor with PureCel®Plus Technology
  • SKU
    OV05C10-A28A-001A-Z
  • Package
    CSP

16:10 Aspect Ratio, 5.2MP Resolution Image Sensor Designed for Laptops and IoT Devices

The OV05C10 image sensor features 5.2‑megapixel (MP) resolution with 1.12 µm pixels and is specially developed for 16:10 aspect ratio notebooks, including mainstream and high-end laptops, tablets and IoT devices. The backside illumination (BSI) image sensor is based on OMNIVISION’s PureCel®Plus technology for higher sensitivity, less noise and better overall image quality. It features two-exposure staggered HDR timing at 5.2MP and 60 frames per second (fps), allowing for improved image quality in bright or dark environments.

At 5.2MP resolution, the OV05C10 image sensor has ample pixels to support auto framing for video conferencing, which automatically adjusts the camera’s field of view to keep the person speaking at the center of the image while cropping out distracting backgrounds. The OV05C10 also supports human presence detection (HPD), which increases the efficiency of artificial intelligence (AI) applications and extends the battery life of portable devices.

November 6, 2023: OMNIVISION Introduces Industry’s First 16:10 Aspect Ratio, 5.2MP Resolution Image Sensor Designed for Laptops and IoT Devices

Supports image sizes:
– 5MP (2888 x 1808)
– 2K (2560 x 1440)
– 1080p (1920 x 1080)
– 720p (1280 x 720), and more

Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports output formats: 10-bit RGB RAW

Two on-chip phase lock loops (PLLs)

Two-wire serial bus control (SCCB)

1024 bytes of embedded one-time programmable (OTP) memory

Image quality control:
– Static defect pixel correction
– Automatic black level calibration

Supports multi-camera synchronization function

Slave SCCB interface for sensor setting, with max 400kHz speed (supports 1MHz with 12MHz ECLK)

  • Spec
    OV05C10
  • Analog / Digital
    Digital
  • Category
    2MP to 5MP
  • CFA (Chroma)
    Color
  • Frame Rate
    Full @ 30 fps (HDR), Full @ 60 fps (Normal)
  • Image Area
    3223.008 x 2017.728 μm
  • Interface
    MIPI
  • Optical Format
    1/4.7"
  • Output Format
    10-bit RGB RAW, 8-bit RGB RAW for ULP
  • Package
    CSP
  • Pixel Size
    1.116 µm
  • Resolution
    5.2MP
  • Shutter Type
    Rolling Shutter
  • Technology
    HDR, PureCel®Plus
  • Use Case
    Notebooks, Tablets
  • Operating Temperature
    -30°C to +85°C
