OMNIVISION’s OV2778 is a 2-megapixel automotive image sensor that offers the best value of any 2MP RGB-IR sensor for cabin- and occupant-monitoring. Built on our OmniBSI™-2 Deep Well™ pixel technology, the OV2778 offers excellent low and NIR light sensitivity, with high dynamic range and advanced ASIL features, reducing artifacts and increasing system reliability. The sensor is ideal for interior applications such as occupant monitoring, detecting packages and unattended children, as well as videoconferencing. It comes in the smallest package available for automotive in-cabin applications—a 6.5 x 5.7 mm automotive CSP package—enabling the smallest camera sizes possible for unobtrusive placement inside the vehicle. It also offers advanced ASIL functional safety, which is important when being integrated as part of an ADAS system.

The OV2778 delivers a 16-bit linear output from a single exposure with best-in-class low-light sensitivity. The dynamic range can be increased to 120 dB, while minimizing motion artifacts from the second exposure. With leading low-light performance, this sensor is ideally suited for in-cabin applications. Additionally, the integrated RGB-IR, 4×4 pattern color filter, along with an external frame synchronization capability allows the sensor to yield the top performance across all lighting conditions.

This image sensor is AEC-Q100 Grade 2 certified for automotive applications. It also benefits from the large installed base of its predecessor, enabling the OV2778 to be easily integrated into existing automotive platforms.
